CORRUGATED BOARD AND BOX MAKING MACHINERY ( PLUS SERIES)
| SPECIFICATIONS |
|---|
| High Speed, Pneumatic Pressure |
| Heavy Duty air blower |
| Auto Gum Circulation |
| Flute A,B,C,E |
| Upper Roll dia: 280 mm |
| Middle Roll Dia: 300 mm |
| Heavy Duty Pressure |
| Speed 35-60 meter depending upon customer’s heating choice |
| Attachable to electric/steam/Oil heating (As per customer’s choice) |
| Size: 1400 to 2000 mm |
| SPECIFICATIONS |
|---|
| Shaft less reel is lifting with multi movement |
| equipped with 6 hydraulic cylinder |
| Heavy duty hydraulic power pack with gauge |
| Highly labour saving and ideal for high speed |
| single facer and lines. |
| Attachable to any type of single facer, reel cutter and other multiple paper reel lifting and unwinding. |
| Mechanical break as standard and Pneumatic breaks as options. |
| Fix type paper core as std and Bulge type as option |
| Size: 1400 to 3000 mm |
| FSHSCDP |
|---|
| Double Flute Corrugation with option to run two flutes in one machine (Flute can be chosen by customer in any of two from A,B,C,E, Flutes machine is fingerless in operation with heavy duty air blower |
| FSHSCDP |
|---|
| High Sped fingerless line with overhead bridge for 2 layerCorrugated Board Attached with sheeter (Options available in our RSC/RSCG/Digital models) Optionally can be attached with Slitter unit and conveyor This model can add extra automations for Corrogated box mfrs for achieving fast process of making corrugated sheet and later convert to boxes. Size: 1400 to 2000 mm |
| TECHNICAL DATA | PFHSCBR | FSHCDP | FSHSCBROH |
|---|---|---|---|
| Size | 42 | 42 | 42 |
| Power | 13 13 15 17 | 17 17 19 21 | 1.3 1.3 1.5 1.5 |
| Speed (meter) | 40-50/min 40-50/min 40-50/min 40-50/min | 30-35/min 30-35/min 30-35/min 30-35/min | 30-35/min 40-50/min 30-35/min 30-35/min |
| Heating Load (Kw) | 42 44 46 50 | 61 61 64 66 | 39 39 41 44 |
| RS Combined Slotter/Slitter/Scorer |
|---|
| Combined Slotter/Slitter/Scorer |
| Ideal for slot/slit/crease on corrugated board. |
| Combined slotting and creasing at a time. |
| TECHNICAL DATA | |||
|---|---|---|---|
| Size | 2200 X 1400 mm | 2400 X 1400 mm | 2800 X 1400 mm |
| Power | 3 Kw | 3 Kw | 3 Kw |
| DCSLE |
|---|
| Lead edge Feeder Printing/Slotting combined touch screen, 1/2/4 Col. option |
| Die cutting option |
| Die Cutting option available as separate unit in this machine |
| TECHNICAL DATA | ||
|---|---|---|
| Max Print | Max Board | Speed |
| 2200 X 1400 mm | 2200 X 1400 mm | 2800 X 1400 mm |
| DCS |
|---|
| Chain Feeder, Printing/Slotting |
| combined, 1/2/4 Col. option |
| Die Cutting option available as separate unit in this machine |
| TECHNICAL DATA | ||
|---|---|---|
| Max Print | 2200 X 1400 mm | 2200 X 1400 mm |
| Max Board | 2200 X 1400 mm | 2600 X 1400 mm |
| Speed | 60 pc/min | 60 pc/min |
| TECHNICAL DATA | |||
|---|---|---|---|
| Size (Width) | 1400 mm | 1600 mm | 1800 mm |
| Length | 300 X 9999 mm | 300 X 9999 mm | 300 X 9999 mm |
| HSCDP Double Profile Single Facer Corrugating Machine |
|---|
| We offer new generation semi and fully automatic machines for corrugating packaging, it includes single facer, sheeter / cut off, gluers, slotting and scorring, die cutting, flexo printing, side gluing, stitching, flute lamination, stacking etc.. |
| Salient Features |
|---|
| Twin flute system easy changeover one to another flute. |
| Hydraulic twin shaft reel loading. |
| Variable speed control. |
| Electric heating and options for thermic /boiler fitting on request. |
| Options for gum circulation & many more. |
| FSHSCBR Fingerless Single Facer Corrugating Machine |
|---|
| Bearing mounted finger less operation with fan and blower for high strength production of corrugation board options of A, B, C, E |
| TECHNICAL DATA | |
|---|---|
| Max Size | 2200 mm |
| TECHNICAL DATA | ||
|---|---|---|
| Max Size | 2460 (L+W) | 1515 (W+H) |
| TECHNICAL DATA | ||
|---|---|---|
| Max Size | 1300 x 1100 mm | 1400 X 1100 MM |
| TECHNICAL DATA | |
|---|---|
| Max Size | 1300 x 1100 mm |
| TECHNICAL DATA | ||
|---|---|---|
| Max Size | 2000 x 1000 mm | 2400 x 1000 mm |
| TECHNICAL DATA | ||
|---|---|---|
| Max Size | 1500 x 1100 mm | 1800 x 1100 mm |
| TECHNICAL DATA | ||
|---|---|---|
| Max Size | 2600 mm | Double servo |
